WATER series liquid cooled vacuum pump
Send an enquiry for an individual quote
SKU: AVVI-VAKUUMNI-POMPI-WATER-SERIES-LIQUID-LLQIH
The WATER series liquid cooled vacuum pumps represent the most elevated standard in vacuum suction technology, designed for agricultural and industrial sectors.
The WATER series vacuum pumps are liquid-cooled radial rotary vane pumps. The body is made of high-resistant cast iron for maximum reliability and heat exchange. They feature a water-recirculating pump, forced lubrication with a piston pump, and an integrated oil tank. Vanes are made of high-heat-resistant composite material. Includes Viton seals for better resistance to high temperatures and an integrated 4-way valve. Inlet and outlet elbows are flanged and can be directed as required. Outlet curves are predisposed for the mounting of a pressure relief valve, vacuum relief valve, and manometer. Technical data: - Pump type: Radial rotary vane pump - Cooling: Liquid cooled (water-recirculating) - Body material: High-resistant cast iron - Seals: Viton - Lubrication: Forced lubrication with piston pump - Capacity PM80 W: 12,000 lt/min (720 m3/h) - Capacity PM110 W: 16,400 lt/min (984 m3/h)
Model *
Drive *
4-way valve actuator type
Complete all required characteristics to continue.
